FFLCE

Fiber lasers are the latest development in laser cutting. The laser beam is created by an active fiber and transmitted over a transport fiber to the machine cutting head. A fiber cutting system is primarily suited for processing thin to medium-thick sheet metal. It also cuts non-ferrous metals such as copper and brass.



Due to their excellent beam quality, fibre lasers are the first choice for diverse applications in the field of laser precision cutting. The fibre laser satisfies customers with its high process speeds and narrow kerfs.



Loyal Wolf Fiber laser cutting processes reduce cycle times providing faster beam for higher cutting speeds, especially for thin materials. It has more advantages comparing other Laser Technologies.



ADVANTAGES;

  • No moving parts or mirrors in the light-generating source, this has a distinct advantage in terms of reducing maintenance requirements and operating costs.
  • Much higher electrical efficiency, resulting in considerably lower running costs.
  • Higher speeds when cutting thin material
  • An ability to cut reflective materials without fear of back reflections damaging the machine. This allows copper, brass, and aluminium to be cut without problems
  • 50% longer servicing intervals and 50% lower servicing costs
  • Material Scrap savings and thus increase productivity
  • Fiber Laser Resonator
  • Raytools Auto Focus Laser Cutting Head
  • LoyalMak CNC
  • Libellula Cut Automatic Nesting Programme
  • 21,5'' Touchscreen
  • Acceleration 1,5G
  • Axes speed (X,Y Traverse Speed) 80 m/min.
  • Positioning accuracy 0,05mm
  • Repeatability 0,02mm
  • Automatic Nozul cleaning and calibration
  • Available with IPG / nLIGHT / RAYCUS fiber laser resonator
  • LoyalMak Filter
  • Light Guard
